HOW TO CHOOSE THE BEST AIR COMPRESSOR AIR FILTER?

What is an Air Compressor Air Filter?

The air filter is an important part of the air compressor. The air filter is usually located at the inlet of the air compressor and is used to remove pollutants from the air before the air enters the compressor. It filters out pollutants before they enter the compressor, thereby protecting the system and ensuring that the compressed air is clean and safe to use.If these contaminants enter the compressor, they can cause wear and tear on the system, leading to reduced efficiency, increased maintenance costs, and even system failure.

How to choose a suitable air filter?

Choosing the right air filter is essential to ensuring the efficiency and life of your air compressor. When choosing an air filter, consider the following factors:

1. Filtration efficiency - The filtration efficiency of an air filter is measured by its minimum efficiency reporting value (MERV). The higher the MERV rating, the more efficient the filter is. For ordinary industrial environments (such as mechanical processing), filters with a filtration accuracy of 5-10μm can be selected; clean industries such as medicine and food need to use high-precision filters of 0.1-1μm to avoid impurities from contaminating the finished product.

2. Airflow - Airflow rate refers to the amount of air passing through the filter in a given time. It is crucial to select a filter that can meet the airflow rate required by the compressed air system. The rated flow of the filter needs to be 10%-20% higher than the maximum air intake of the air compressor to avoid increased intake resistance due to insufficient flow, which affects the efficiency of the air compressor.

3. Pressure drop - Pressure drop refers to the drop in air pressure flowing through the filter. Excessive pressure drop will have a negative impact on the efficiency of the compressed air system. Choose a filter with a compact filter element structure and high air permeability (such as a folded filter element). The pressure loss should be ≤0.03-0.05MPa during normal operation, otherwise it will increase energy consumption.

4. Environmental factors - Consider the environmental factors of the compressed air system, including temperature, humidity, and the presence of oil or water in the air. For high temperature environments, you need to choose heat-resistant materials (such as metal frame filter elements); for humid environments, it is recommended to use waterproof coating filter elements or pre-gas-water separators. If the air contains oil mist or chemical gases, you need to use a composite filter with an activated carbon layer, or add a post-precision filter device.

Air filter maintenance:

Proper maintenance of compressor air filters is essential to ensure their effectiveness and life. Filters should be checked regularly and replaced as needed. Observe the pressure differential indicator (red alarm prompts replacement) and usually replace every 2,000 to 8,000 hours.

Hope the above content is helpful to you. Qingdao Futai is your one-stop supplier of all air compressor parts to keep your air compressor at its best performance. If you are interested in our products and want to know more, please click the message icon in the lower right corner and select the contact information you want to use to contact us.
